High flexibility pure copper EV cable, 10/16/25/35/50/70 square mm single core high voltage EV battery cable

High flexibility pure copper EV cable, 10/16/25/35/50/70 square mm single core high voltage EV battery cable

XLPE Shielding Cable

Automotive XLPE Shielding Cable

Automotive XLPE Cable

Place of Origin:

China

Brand Name:

Linke

Certification:

3C,UL,TPU,UL758,ROHS,REACH,CE,ISO9001-2015,ISO13485,IATF16949

Contact Us
Request A Quote
Product Details
Jacket:
Silicone
Insulation:
XLPE
Type:
Insulated
Conductor Type:
Twisted Wire
Voltage Rating:
600V
Sheath Material:
FEP
Rated Voltage:
3000V
Current:
DC & AC
Property:
High Temperature Resistance
Amp:
1200A
Material:
Silicone Rubber
Core:
Multiple
Conductor Material:
Copper/Tinned Copper
Exterior Material:
Customize:PVC、PE、LSFOH、silicone Rubber
Insulating Materials:
Customize:PVC、PE 、XLPE、EPR、SIR
Specifications:
0.1-450mm²
Colour:
Customize
Customization:
Available
Highlight:

XLPE Shielding Cable

,

Automotive XLPE Shielding Cable

,

Automotive XLPE Cable

Payment & Shipping Terms
Minimum Order Quantity
1000m
Price
Negotiable
Packaging Details
According to requirement
Delivery Time
7-15 days
Payment Terms
Advance 30% deposit and ship after receiving 70% final payment
Supply Ability
50000m/day
Product Description

custom flexible high temperature heat-resistant electrical silicone rubber insulation shield cables manufacturer

Product Description

New Energy XLPE Shielding Cable Automotive High Voltage Wire

Product Item EV-XLPE Cable
Country of Origin China
Production Specification According to customer requirements
Insulation Material XLPE
Rated Tempature -40~125°C
Color Yellow, Green, Black, Red, Grey, Brown, Blue, Qrange, White and Transparent
Rated Voltage(U0/U) 1500V





EV Cable High flexibility pure copper EV cable, 10/16/25/35/50/70 square mm single core high voltage EV battery cable 1

Specifications





Conductor Insulation



Conductor Resistance

(Ω/KM)



Size(mm2)



Construction(No./mm)



Diameter(mm)



Nominal thickness(mm)



Diameter(mm)

4 133/0.20BS 2.80 0.80 4.40±0.20 ≤4.70
6 190/0.20BS 3.40 0.80 5.00±0.20 ≤3.10
10 259/0.20BS 4.50 1.00 6.50±0.30 ≤1.82
16 323/0.20BS 5.70 1.20 8.10±0.30 ≤1.16
25 513/0.20BS 7.20 1.40 10.00±0.30 ≤0.743
35 798/0.20BS 8.50 1.40 11.30±0.40 ≤0.527
50 1121/0.20BS 10.50 1.60 13.70±0.50 ≤0.368
70 1596/0.20BS 12.50 1.80 16.00±0.50 ≤0.259
95 2257/0.20BS 14.80 2.00 18.80±0.70 ≤0.196
120 1887/0.254BS 16.50 2.20 20.80±0.70 ≤0.153

High flexibility pure copper EV cable, 10/16/25/35/50/70 square mm single core high voltage EV battery cable 2
High Voltage EV Cable
Electric vehicle high-voltage lines are used to connect charging ports and batteries, battery interiors, batteries and engines and other components, as well as battery energy storage equipment and other fields, as a carrier of power transmission. Due to the harsh application environment in the vehicle, the high-voltage line of electric vehicles has very high performance requirements.
Specifications
Model
High Voltage EV Cable
Conductor
Class 5 copper conductor
No. of Cores
single core
Conductor Type
stranded
Insulation
XLPE
Jacket(Sheath)
XLPE
Standards
BS EN 50618:2014
DC
1.5 KV
AC
1.0/1.0 KV
Nominal cross-sectional area of conductor(mm²)
4~150(mm²)
Colors
Black or custom
Ambient temperature
-40℃ ~+150℃
Details Images
High flexibility pure copper EV cable, 10/16/25/35/50/70 square mm single core high voltage EV battery cable 3
High flexibility pure copper EV cable, 10/16/25/35/50/70 square mm single core high voltage EV battery cable 4
About Us

New Energy XLPE Shielding Cable Automotive High Voltage Wire


   We have a strong R&D team,6 people in the engineering department,they all have more than 10 years of technology and experience in the field of wire and cable,professional focus on wire and cable solutions to ensure that we provide the most accurate and effective solutions to our customers.The quality control department has 10 people,from inxoming materials to shipping,esch step is strictly supervised to ensure that the products reach the customer's hands are 100% good.The production staff has more than 50 people, who are experienced in prodution.


PRODUCTION WORKSHOP

New Energy XLPE Shielding Cable Automotive High Voltage Wire
New Energy XLPE Shielding Cable Automotive High Voltage Wire
New Energy XLPE Shielding Cable Automotive High Voltage Wire

New Energy XLPE Shielding Cable Automotive High Voltage Wire
New Energy XLPE Shielding Cable Automotive High Voltage Wire
New Energy XLPE Shielding Cable Automotive High Voltage Wire

New Energy XLPE Shielding Cable Automotive High Voltage Wire
New Energy XLPE Shielding Cable Automotive High Voltage Wire
New Energy XLPE Shielding Cable Automotive High Voltage Wire

CABLE TESTING LABORATORY

New Energy XLPE Shielding Cable Automotive High Voltage Wire
New Energy XLPE Shielding Cable Automotive High Voltage Wire

New Energy XLPE Shielding Cable Automotive High Voltage Wire
New Energy XLPE Shielding Cable Automotive High Voltage Wire


New Energy XLPE Shielding Cable Automotive High Voltage Wire
New Energy XLPE Shielding Cable Automotive High Voltage Wire
FAQ

1. Are you a manufacturer or trading company?
We are a professional manufacturer. We can control your order from the first begining to the last. Welcome to visit us. We'll pick you up in Shenzhen.


2. How can I get a sample to test your quality?
The samples are free for you. New clients are expected to pay for the courier cost.



3. What's your Minimum Order Quantity?
Normally 100m. However, the cable is very heavy. You'd better order a suitable quantity to avoid the high freight. Sea transportation is the best option.


4. Can I get a discount?
It depends on your quantity, We can make a discount and afford the freight. Pls kindly contact us.


5. Does your company accept OEM production?
Yes, could print your company name, we even custom the quality card to promote your company.

For More Information, Please do feel free to contact us!
