TPE Sheath UL Electrical Cable For Electrical Connection And Copper Wire Electrical signal line Electrical control line Electrical extension cord Internal wiring of electrical appliances

TPE Sheath UL Electrical Cable For Electrical Connection And Copper Wire Electrical signal line Electrical control line Electrical extension cord Internal wiring of electrical appliances

TPE Sheath UL Electrical Cable

Copper Wire UL Electrical Cable

FEP Insulation UL Cable

Place of Origin:

Guangdong, China

Brand Name:

Linke

Certification:

3C,UL,TPU,UL758,ROHS,REACH,CE,ISO9001-2015,ISO13485,IATF16949

Contact Us
Request A Quote
Product Details
Model NO.:
UL 21481 Cable
Insulation Material:
FEP/HDPE/PP/PVC
Insulation:
FEP/HDPE/PP/PVC
Conductor Type:
Twisted Wire
Conductor Material:
Copper/Tinned Copper
Exterior Material:
Customize:PVC、PE、LSFOH、silicone Rubber
Insulating Materials:
Customize:PVC、PE 、XLPE、EPR、SIR
Colour:
Customize
Package:
By Roll
Lead Time:
7-15days
Highlight:

TPE Sheath UL Electrical Cable

,

Copper Wire UL Electrical Cable

,

FEP Insulation UL Cable

Payment & Shipping Terms
Minimum Order Quantity
1000m
Price
Negotiable
Packaging Details
According to requirement
Delivery Time
7-15day
Payment Terms
Advance 30% deposit and ship after receiving 70% final payment
Supply Ability
50000m/day
Product Description

TPE Sheath UL Electrical Cable For Electrical Connection Electrical signal line Electrical control line Electrical extension cord Internal wiring of electrical appliances


Product Description

 The cable is widely used in home appliance, lighting, heater, moter and generator, UAV, robot, industrial power etc.
Factory Direct Sales UL Cable PVC Insulated Copper Connecting Wire Electrical Cable


Factory Direct Sales UL Cable PVC Insulated Copper Connecting Wire Electrical Cable

Product Specification

Thermoplastic elastomer wire & cable TPE wire&Cable



UL Style Number:21481



 Specifications

Rated voltage: 300V

Rated Temperature: 80℃

Standard: UL758/UL1581

Applications



Internal wiring.

印字Marking:E364879 TPE Sheath UL Electrical Cable For Electrical Connection And Copper Wire Electrical signal line  Electrical control line  Electrical extension cord  Internal wiring of electrical appliances 2 AWM 21481 **AWG VW-1 80℃ 300V CTPE Sheath UL Electrical Cable For Electrical Connection And Copper Wire Electrical signal line  Electrical control line  Electrical extension cord  Internal wiring of electrical appliances 3 AWM I A 80℃ 300V FT1 Linke Cable



Conductor Insulation Core

Shield



Jacket

 Max.

Conductor Resistance

(Ω/KM)



Size

(AWG)



Construction

(No./mm)



Diameter

(mm)



Nominal thickness

(mm)



Diameter

(mm)

Optional



Shield Rate

(%)



Nominal thickness(mm)



Diameter

(mm)



Bare copper



Tinned copper

26 7/0.16 0.48 0.38 1.30±0.10 2 Optional 0.76 4.10±0.15 140 150
3 4.30±0.15
4 4.70±0.15
24 7/0.20 0.60 0.38 1.40±0.10 2 Optional 0.76 4.30±0.15 87.6 94.2
3 4.50±0.15
4 4.90±0.15
22 7/0.254 0.78 0.38 1.60±0.10 2 Optional 0.76 4.70±0.15 55.4 59.4
3 5.00±0.15
4 5.40±0.15
20 26/0.16 0.94 0.38 1.80±0.10 2 Optional 0.76 5.10±0.15 34.6 36.7
3 5.40±0.15
4 5.90±0.15
18 41/0.16 1.18 0.38 2.10±0.10 2 Optional 0.76 5.70±0.15 21.8 23.2
3 6.00±0.20
4 6.60±0.20
16 26/0.254 1.49 0.38 2.40±0.10 2 Optional 0.76 6.30±0.20 13.7 14.6
3 6.70±0.20
4 7.30±0.25

Note: Wire specifications can be customized

颜色 Colours:黑色(Black),棕色(Brown),红色(Red),橙色(Orange),黄色(Yellow),绿色(Green),蓝色(Blue),紫色(Purple),灰色(Gray),

白色(White),黄/绿(Yellow/Green),透明(Transparent)

Company Profile

Wire and cable manufacturer Linke Cable Technology Co., Ltd is a leading cable supplier in China.

In the past over 10 years, Linke Cable has been focusing on R&D, production and marketing of

wire and cable. Linke provide various cables&custom cable solutions for all over the world.

We are specialized in EV charging cable, medical cable, silicone cable, spring cable, braided cable,

towlobe cable, UL wire, automotive cable, etc.

At Linke cable, we believe there's a better way to bring better cables to market. We use an engineer-to-

engineer approach to develop better cables for customers and  improve the quality of one's life.

Exhibition:


Factory Direct Sales UL Cable PVC Insulated Copper Connecting Wire Electrical Cable
Factory Direct Sales UL Cable PVC Insulated Copper Connecting Wire Electrical Cable


About Us



Factory Direct Sales UL Cable PVC Insulated Copper Connecting Wire Electrical Cable

We have a strong R&D team,6 people in the engineering department,they all have more than 10 years of technology and experience in the field of wire and cable,professional focus on wire and cable solutions to ensure that we provide the most accurate and effective solutions to our customers.The quality control department has 10 people,from inxoming materials to shipping,esch step is strictly supervised to ensure that the products reach the customer's hands are 100% good.The production staff has more than 50 people, who are experienced in prodution.


Factory Direct Sales UL Cable PVC Insulated Copper Connecting Wire Electrical Cable


Certifications

We past UL1007,UL1185,UL1672,UL10070,UL10483,UL1015,UL1569,UL10012,UL10269

(Single conductor,thermoplastic insulation)
UL2095,UL2129,UL2468,UL2586,UL2725,UL20233,UL20280,UL20963,UL2103,UL2463,UL2517,UL2587,

UL2835,UL20276,UL20549,UL21198,2104,UL2464,UL2576,UL2661,UL2919,UL20279,UL20886,UL21664

ISO9001 and ISO13485,TS16949

CNR- Appliance Wiring Material,

Extruded PVC Insulated Single,rated 105ºC,1000V,ClassI,GroupA,B,or AB, FT1 and/or FT2.

Extruded PVC Non-integral Jacketed Cable, rated 105"C, 1000V, Class I, Class or Class I/Il, Group A, B, or AB, FT1 and/or FT2.
Extruded TPU Non-integral Jacketed Cable, rated 80"C, 300V, Class I, Class or Class I/Il, Group A, B, or AB, FT1 and/or FT2.

Single-conductor, thermoplastic insulation
1007 1330 1333 1591 1723 10064 10369
1015 1331 1569 1592 1901 10070 10483
1185 1332 1577 1672 10012 10269
Multiple-conductor, thermoplastic insulation
2095 2129 2468 2586 2725 20233 20280 20963
2103 2463 2517 2587 2835 20276 20549 21198
2104 2464 2576 2661 2919 20279 20886 21664
Single-conductor, thermoset insulation
3075 3173 3320 3386 3530 3689 30005
3123 3212 3321 3398 3577 3702
3132 3266 3331 3512 3644 3817
3135 3271 3385 3529 3674 3886




Factory Direct Sales UL Cable PVC Insulated Copper Connecting Wire Electrical Cable
Factory Direct Sales UL Cable PVC Insulated Copper Connecting Wire Electrical Cable

FAQ

1. Are you a manufacturer or trading company?
We are a professional manufacturer. We can control your order from the first begining to the last. Welcome to visit us. We'll pick you up in Shenzhen.


2. How can I get a sample to test your quality?
The samples are free for you. New clients are expected to pay for the courier cost.



3. What's your Minimum Order Quantity?
Normally 100m. However, the cable is very heavy. You'd better order a suitable quantity to avoid the high freight. Sea transportation is the best option.


4. Can I get a discount?
It depends on your quantity, We can make a discount and afford the freight. Pls kindly contact us.


5. Does your company accept OEM production?
Yes, could print your company name, we even custom the quality card to promote your company.

For More Information, Please do feel free to contact us!
