Gxl Flexible PVC Wire Cable for Automobile Internal Powerline Wiring
Battery car cable
Battery cables are usually larger in size and are mainly used to connect batteries to the electronic systems and grounding of cars. So the overall product is relatively heavy. These cables are composed of bare copper conductors and offer standard battery circuit colors of black and red.
Connect car cables
Connecting car wires is a copper wire with a single insulated conductor, which can be solid or twisted. The protective sheath of the connecting wire can be made of PVC, chloroprene rubber, silicone rubber, etc. The most popular types of wires in automotive applications are TEW UL1015 (thermoplastic elastomer wire) or motor wire. This type of motor wire is commonly used for internal wiring of electrical appliances and HVAC equipment.
Car speaker cable
Car speaker cables are used to establish electrical connections between speakers and audio amplifiers. The speaker cable consists of two or more electrical conductors, insulated with PVC, PE, or Teflon rubber. These two lines have the same electrical performance and are generally marked in red and black to identify the correct polarity of the audio signal. Speaker cables are commonly found in parallel zippers and are used for 12V power supply.
Trailer cable
Trailer cables are the most commonly used automotive wires for towing vehicles, trailers, and other heavy equipment. This wire supplies power to the trailer's lights, including taillights, brake lights, and turn signals. The trailer cable is an integral part of the trailer connector safety system and is suitable for any towing application.
If you need to purchase automotive cables, we are willing to provide you with all automotive cables at any time. Including car wires, motor wires, car horn wires, trailer wires, battery wires, brake wires, etc. There are multiple configurations to choose from, and if you are unsure which type your application requires, our professional sales team is always at your service and at your disposal. The KUKA cable team is willing to help you solve any problems.
Product Name: American Standard GXL Irradiation Cross-linked Polyolefin Automotive Low Voltage Wire
Conductor structure: Use twisted 20AWG ~ 8AWG tinned copper wire or bare copper wire
Rated temperature: 125℃
Rated voltage: 50V
Temperature range: -40℃～155℃
Product application range: Used for low-voltage connecting wires for the internal electrical system of automobiles; connecting wires for electrical appliances and instruments of automobiles, motorcycles and other vehicles.
| Product Name | American standard thin wall low pressure | brand | LINKE |
|---|---|---|---|
| conductor | Use stranded 20AWG ~ 8AWG tinned copper or bare copper wire | ||
| insulation |
Cross-linked polyolefin ( XLPE); thermoplastic elastomer insulation, compliant with ROHS and REACH environmental standards |
color | Any color or two colors |
| characteristic |
Use standard insulation thickness, easy to cut and strip wires; It has high softness, acid and alkali resistance, oil resistance, heat resistance and cold resistance; Flame retardant, wear resistant, moisture resistant, mildew resistant, good mechanical properties and thermal stability; It has the characteristics of high and low temperature resistance and friction resistance. |
Rated temperature | 125°C |
| Operating temperature |
-40℃～155℃ |
Rated voltage | 50V |
| Environmental testing | Complies with EU RoHS environmental directive and passed SGS testing | Packing meters | 500m/roll |
|
Usage scenarios |
Used for low-voltage connecting wires for the internal electrical system of automobiles; connecting wires for electrical appliances and instruments of automobiles, motorcycles and other vehicles. |
||
Wire and cable manufacturer Linke Cable Technology Co., Ltd is a leading cable supplier in China.
In the past over 10 years, Linke Cable has been focusing on R&D, production and marketing of
wire and cable. Linke provide various cables&custom cable solutions for all over the world.
We are specialized in EV charging cable, medical cable, silicone cable, spring cable, braided cable,
towlobe cable, UL wire, automotive cable, etc.
At Linke cable, we believe there's a better way to bring better cables to market. We use an engineer-to-
engineer approach to develop better cables for customers and improve the quality of one's life.
| Single-conductor, thermoplastic insulation | |||||||
| 1007 | 1330 | 1333 | 1591 | 1723 | 10064 | 10369 | |
| 1015 | 1331 | 1569 | 1592 | 1901 | 10070 | 10483 | |
| 1185 | 1332 | 1577 | 1672 | 10012 | 10269 | ||
| Multiple-conductor, thermoplastic insulation | |||||||
| 2095 | 2129 | 2468 | 2586 | 2725 | 20233 | 20280 | 20963 |
| 2103 | 2463 | 2517 | 2587 | 2835 | 20276 | 20549 | 21198 |
| 2104 | 2464 | 2576 | 2661 | 2919 | 20279 | 20886 | 21664 |
| Single-conductor, thermoset insulation | |||||||
| 3075 | 3173 | 3320 | 3386 | 3530 | 3689 | 30005 | |
| 3123 | 3212 | 3321 | 3398 | 3577 | 3702 | ||
| 3132 | 3266 | 3331 | 3512 | 3644 | 3817 | ||
| 3135 | 3271 | 3385 | 3529 | 3674 | 3886 | ||
